• Very silent printing thru direct thermal printing method
• Print speed 70mm/s
• Support Bluetooth Ver3.0/4.0[BLE] Dual Mode
• Support Secure Magnetic Stripe Reader <Model with Card Reader>
*AES or 3DES encryption
*DUKPT Key Management
• Belt Clip as a standard accessory
• Support text and graphic printing
• Drop-in design that makes it easy to load paper
• A printer cover that can be opened with the touch of a button
• Printer cover open sensor, Paper-out sensor, Black mark sensor, Label gap detection
，
| Printing | Print Method | Direct Thermal |
| Resolution | 203 dpi (8 dots/mm) | |
| Print Speed | Max.70 mm/s | |
| Print Width | 48 mm/72 mm | |
| Interface | USB, Bluetooth3.0/4.0 | |
| Power Saving | Sleep Mode | YES |
| Memory | RAM | 4 MB |
| Flash | 8 MB | |
| Programming Language | ESC/POS | |
| Fonts | Alphanumeric; Simplified Chinese, Traditional Chinese; 42 International Character Sets | |
| Barcode | Linear Barcodes | UPC-A, UPC-E, EAN-8, EAN-13, CODE39, ITF, CODEBAR, CODE 128, CODE 93 |
| 2D Barcodes | PDF417, QR Code | |
| Graphics | Support bitmap printing with different density and user defined bitmap printing | |
| Interface | Standard | MicroUSB, Bluetooth 3.0/4.0 |
| Option | N/A | |
| Sensors | Standard | Paper out Detector, Cover open Detector, Black mark Detector, Gap Detector |
| Option | N/A | |
| LED indicator | Power | Green |
| Error | Red | |
| Power | Input | AC 100 ~ 240 V, 50/60 Hz |
| Output | DC 5V, 1A | |
| Battery | 7.4V rechargeable Li-polymer battery, 2300mAh | |
| Paper | Type | Continuous paper, black mark paper, linerless label, gap label |
| Width | 80 mm | |
| Thickness | 0.053 ~ 0.13 mm | |
| Diameter of Paper Roll | Max. Φ50 mm (O.D) | |
| Paper Loading | Easy loading mechanism | |
| Physical Characteristics | Working Condition | -5°C ~ 50°C, 25% ~ 85% R.H, no-condensing |
| Storage Condition | -30°C ~ 60°C, 5% ～ 95% R.H, no-condensing | |
| Dimension | 138.8(L)×106.3(W)×61.2(H) mm | |
| Weight | 0.476 kg | |
| Options and Accessories | USB Cable, Belt Clip, Docking Cradle, Paper Roll, Quick Start Guide, CD | |
| Software | Driver | HPRT Driver：Windows XP，Vista,7，8，10.Linux,Mac |
| SDK | WinCE, Windows Mobile, Android, iOS | |
